Tsunami QB-8100 Series (100 Mbps/5 Mbps Models) Installation and Management Guide 163
The following table lists the parameters and their descriptions:
6.4.4 RIP Database
This section shows the information about the RIP database. It contains routes (Routing Information Protocol updates) learnt
from other routers.
Field Description
In Msgs/Out Msgs The number of ICMP messages that are received/transmitted by the
device.
In Errors/Out Errors The number of ICMP messages that the entity received/transmitted but
determined as having errors.
In Dest Unreachs/
Out Dest Unreachs
The number of ICMP Destination Unreachable messages
received/transmitted.
In Time Excds/Out Time Excds The number of ICMP Time Exceeded messages received/transmitted.
In Parm Probs/Out Parm Probs The number of ICMP Parameter Problem messages received/transmitted.
In Srec Quenchs/Out Srec Quenchs The number of ICMP Source Quench messages received/transmitted.
In Redirects/Out Redirects The rate of ICMP Redirect messages received/transmitted.
In Echos The rate of ICMP Echo messages received.
NOTE: Out Echos parameter is not displayed in the ICMP
statistics list.
In EchoReps/Out EchoReps The rate of ICMP Echo Reply messages received/transmitted.
In Timestamps/Out Timestamps The rate of ICMP Timestamp (request) messages received/transmitted.
In Timestamps Reps/
Out Timestamps Reps
The rate of ICMP Timestamp Reply messages received/transmitted.
In Addr Masks/Out Addr Masks The number of ICMP Address Mask Request messages
received/transmitted.
In Addr Mask Reps/ Out Addr Mask
Reps
The number of ICMP Address Mask Reply messages
received/transmitted.
