Tsunami QB-8100 Series (100 Mbps/5 Mbps Models) Installation and Management Guide 213
Management
Power Supply
LEDs
Category Specification
Local RS232 serial CLI (up to 115200 bps)
Remote • Telnet and SSH, Web GUI (http) and SSL (https), TFTP
• SNMP v1, v2c and v3
• SNMP trap and Syslog
Category Specification
Input Voltage • Via RJ-45 Ethernet interface supplying 48v and 0.40A on
Ethernet Port
• 12 V-DC through serial port (for diagnostic purpose)
• Consumption 13.8 Watts typical (19 Watts max)
Power over Ethernet Injector • Input : 100 – 250 V-AC (47 – 63 Hz)
• Output : 48 V-DC at 0.40 A (19 Watts)
• Pin-out : +48 V on pins 4/5, -48 V on pins 7/8
• Size : 3.98x2.40x1.35 inches (101.0x61.5x32.2 mm)
• Weight : 5.6 ounces (160 g)
• Temp : 0 to 40 ºC
Category Specification
Types Power
Radio Activity
Ethernet Activity
RJ-11 detection
