Tsunami QB-8100 Series (100 Mbps/5 Mbps Models) Installation and Management Guide 125
4.11.3 RIP (Routing Mode Only)
Routing Information Protocol (RIP) is a dynamic routing protocol, which can be used to automatically propagate routing table
information between routers. The unit can be configured to operate in RIPv1, RIPv2, or both.
When a router receives a routing update including changes to an entry, it updates its routing table to reflect the new route.
RIP maintains only the best route to a destination. Therefore, whenever new information provides a better route, the old
route information is replaced.
NOTE: RIP is configurable only when the unit is in Routing Mode and Network Address Translation (NAT) is disabled.
To enable RIP functionality
• Enable RIP status from the drop-down menu. RIP runs on per interface basis.
To configure RIP parameters
1. Click ADVANCED CONFIGURATION > Network > RIP. The RIP screen is displayed as shown below.
S.No. Protocol Support Applications
1 H.323 H.323 ALG Multimedia Conferencing
2 HTTP Port Mapping for
inbound connection
Web Browser
3 TFTP Port Mapping for
inbound connection
Trivial file transfer
4 Telnet Port Mapping for
inbound connection
Remote login
5 IRC Port Mapping for
inbound connection
Chat and file transfer
6 AMANDA Port Mapping for
inbound connection
Backup and archiving
7 FTP FTP ALG File Transfer
8 PPTP PPTP ALG VPN related
9 NETBIOS Port Mapping for
inbound connection
Applications on different
computers can
communicate within a LAN
10 SNMP SNMP ALG Network Management
11 DNS Port Mapping for
inbound connection
Domain Name Service
To Next Page
