Tsunami QB-8100 Series (100 Mbps/5 Mbps Models) Installation and Management Guide 55
TPC With Transmit Power Control (TPC), you can adjust the output
power of the device to a lower level. This is performed to reduce
interference with the neighboring devices. It can be helpful
when higher gain antenna is used without violating the
maximum radiated output power for a country or regulatory
domain. This value can be configured in 1 dB increments.
NOTES:
• This feature only lets you decrease the output
power; it does not let you increase the output power
beyond the maximum allowed defaults for the
selected frequency and country.
• The range of values depend on the Cell Size.
Active TPC If the feature Automatic Transmit Power Control (ATPC) is
enabled automatically, this field appears for United States 5 GHz
frequency domain only.
NOTE: This field is not displayed for United States 5.8
GHz frequency domain.
Antenna Gain The sensitivity of the radio card can be modified when detecting
radar signals in accordance with ETSI, FCC, and IC Dynamic
Frequency Selection (DFS) requirements. As the radar detection
threshold is fixed by ETSI, the FCC, and IC and a variety of
antennas with different gains may be attached to the device, you
must adjust this threshold to account for higher than expected
antenna gains. This can avoid false radar detection events which
can result in frequent change in the Frequency channels.
Configure the threshold for radar detection at the radio card to
compensate for increased external antenna gains. The Antenna
Gain value ranges from 0 to 40. The default value is 0.
NOTE: Modifying any of the wireless parameters results
in temporary loss of connectivity between the End
Point A and End Point B.
Wireless Inactivity Timer Resets the wireless interface if there is no change in the Tx and
Rx Packet Count in the specified interval of time. The default
value is set to 0 minutes (disabled) and can be configured
between 0 to 600 minutes.
Parameter Descriptions
