Advanced Configuration
Tsunami QB-8100 Series (100 Mbps/5 Mbps Models) Installation and Management Guide 64
Table 4-1 Data Rates to Rate Index Mapping Table
Table 4-2 DDRS Minimum Required SNR Table
When DDRS Status is enabled, the DDRS Status field is displayed and WORP Tx Rate is disabled in BASIC
CONFIGURATION Screen. See Basic Configuration Information for more details. Also when enabled, the DDRS Status field
is displayed and WORP Tx Rate is also disabled in ADVANCED CONFIGURATION > Wireless > Interface 1 > WORP
screen. See Configuring WORP Properties in End Point A Mode for more information.
Rate
Index
Data Rates (Mbps)
5 MHz Channel
Bandwidth (for
Full GI-800ns)
10 MHz Channel
Bandwidth (for
Full GI-800ns)
20 MHz Channel
Bandwidth (for
Full GI-800ns)
40 MHz Channel Bandwidth
Longer
Range
Higher
Through
put
Longer
Range
Higher
Through
put
Longer
Range
Higher
Through
put
Short GI-400ns Full GI-800ns
Longer
Range
Higher
Through
put
Longer
Range
Higher
Though
put
1 1.6 3.3 3.3 6.5 6.5 13 15 30 13.5 27
2 3.3 6.5 6.5 13 13 26 30 60 27 54
3 4.9 9.7 9.7 19.5 19.5 39 45 90 40.5 81
4 6.5 13 13 26 26 52 60 120 54 108
5 9.7 19.5 19.5 39 39 78 90 180 81 162
61326265252104120240108216
7 14.6 29.3 29.3 58.5 58.5 117 135 270 121.5 243
8 16.2 32.5 32.5 65 65 130 150 300 135 270
Rate Index Legacy Mode Enabled
Minimum Required SNR (dB)
Single Stream Dual Stream
17 9
210 13
313 16
416 19
520 25
625 28
728 31
831 34
