PRÜFTECHNIK OPTALIGN smart RS5 BT User Manual

OPTALIGN smart RS5 BT handbook
70
32
RS5 BT sensor
4
horizontal
vertical
It is highly recommended
that before mounting
the laser on its bracket,
both yellow adjustment
thumbwheels be brought
to the approximate center
of their travel range. This
will ensure that the beam
is emitted from the laser
as straight as possible
and not at an angle.
Also make sure both
brackets are rotationally
aligned to each other.
These precautions will
greatly facilitate the beam
adjustment process.
1
RS5 laser
ON/OFF push
button switch
Laser beam adjustment

PRÜFTECHNIK OPTALIGN smart RS5 BT Specifications

General

Brand	PRÜFTECHNIK
Model	OPTALIGN smart RS5 BT
Category	Laser Shaft Alignment Tools
Language	English
