Page 9
Product Specification
Physical
Outside dimensions 210 x 125 x 50 mm
(8.27 x 4.92 x 1.97 inch)
Weight Nominal 0.6 kg (1.3 lbs)
Enclosure material/description Polycarbonate UL94 V2 rated, with
weather-proof connectors.
Screen 3.2” TFT LCD
Supplied cable length 2 metres (9.8 ft.) minimum
Environmental
IP Rating (enclosure and connectors) IP65
Max. & min. temperature (electronics) -20 ºC to +60 ºC (-4
o
F to 140
o
F)
Max. & min. temperature (battery charging) +0 ºC to +40 ºC (+32
o
F to 104
o
F)
for charging batteries
CE approval See EU Declaration of Conformity
Data Logging
Storage media Internal Flash Memory
Storage capacity 3.8 GB
3.2 million entry without trace
800 000 entries with trace
Storage format PC files
Storage access File transfer to PC via USB – no driver
required.
Outputs
Analogue output Not available
Digital output Half Duplex RS485 to sensor
USB Connection to PC for file transfer
Programming
Programmed parameter integrity Via non-volatile RAM
Supply
Rechargeable battery 11.1 VDC Li-ion cells
Battery duration 4 – 5 hours
Charging methods Mains charger, 12 VDC@2A
In-car charger
Power supply DC 12-18V,
Power Consumption 3.5W @ 12V not charging
15W @ 12V when charging
Pulsar Process Measurement Limited operates a policy of constant development and
improvement and reserve the right to amend technical details as necessary.
