GETTING STARTED QT426 User Manual
8 | Page
2. GETTING STARTED
Check the unit and the accessories immediately after opening your system.
Please disconnect the power before connecting to other devices.
2.1 Installing Hard Drive
This device supports one SATA hard drive up to 2TB.
Calculate HDD capacity according to the recording settings. Please refer to “Appendix B Calculate Recording
Capacity”.
Step 1: Unscrew and Open the top cover
Step 2: Connect the power and data cables. Place the HDD onto the bottom case as shown below.
Fig 2.1 Connect HDD
Step 3: Screw in the HDD as shown below.
Note: For easier installation, please connect the power and data cables first, and then screw the HDD to
base.
Fig 2.2 Screw in the HDD
