Quantronix CUBISCAN 25 User Manual

Communication Protocol CubiScan 25 Command Set
CubiScan 25 Service Manual 54
The CubiScan 25 responds with a question mark NACK to any unrecognized Command. For
example:
<STX><?><N><ETX><CR><LF>
When a NACK is sent by the CubiScan 25, the operation associated with that command is aborted
due to the error.
Command Set Summary
The CubiScan 25 recognizes the following commands from the command set for a serial, USB, or
Ethernet connection.
The table below shows the Command Set Summary.
(A) - Command Character
(B) - Command Hex Value(s)
User Command Name (A) (B) Page
“Build Number” b 62h 55
“CubiScan 100 Compatible Measure
Mode”
M4Dh 56
“Dimension Units” “ 22h 57
“Emitter Toggle” e 65h 58
“Factor Table” f 66h 59
“Factor Toggle” F 46h 60
“Flash Firmware” l 6Ch 60
“Gate Measure” m 6Dh 61
“Identification/Serial Number” I 49h 63
“Key Coordinates” k 6Bh 64
“Location Identification” L 4Ch 64
“Model” ! 21h 65
“Reset System” x 78h 66
“Save Parameters” s 73h 67
“Scale Calibration” S 53h 67
“Scrape Screen” a 61h 68
“Serial Get” g 67h 69
“Serial Loop Back” P 50h 70
“Serial Put” p 70h 71
“Smallest Box Mode” j 6Ah 72
“Test” T 54h 72
