QXS System and Cabinet Information 5
General Cabinet Information
This section includes the following information:
Standard Cabinet
Cabinet Height
Cabinet Vertical Support Rails
Cabinet Configurations with Chassis and Drives
Standard Cabinet
Figure 7 provides an image of a standard cabinet which includes locations of the following:
Front door
Rear door
Vertical support rails
Air vent
Figure 7 Standard Cabinet
1 Front door 2 Rear door
3 Vertical support rails 4 Air vent
12
3
4
