QXS-324/424 12G System Specifications 23
2U24-Drive RAID and Expansion Chassis Weight
Tab l e 12 identifies the weight of the QXS-324/424 12G RAID and expansion chassis.
Bezel
The 2U24 drive chassis includes a bezel sub-assembly that attaches to the front panel of the chassis.
The bezel, comprised of a vented cover attached to an electro-magnetic interference (EMI) shield, is
pre-assembled and packed within a box contained in the enclosure master shipping container.
Instructions for attaching/removing the bezel are provided in the
QXS 12G Hardware Installation and
Maintenance Guide
.
CAUTION: The bezel should be properly installed while the chassis is in operation to ensure
adequate EMI protection for the drives.
Depth from face of Ops panel to rearmost chassis extremity 629.6 mm 24.79 in
Note: The 2U24 chassis uses 2.5" SFF disks.
Ta bl e 1 1 (continued)Chassis Dimensions
Specification Metric Unit Imperial Unit
Ta b le 1 2 Chassis Weights
CRU/Component 2U24 (kg/lb)
Storage chassis (empty) 4.8/10.56
Disk drive carrier 0.3/0.66
Dummy disk drive carrier (air management sled) 0.05/0.11
2U Power Supply Unit (PSU) 3.5/7.7
5U Power Supply Unit (PSU) -
5U Fan -
Controller (module in RAID chassis) 2.6/5.8
Expansion IOM (module in expansion chassis) 1.5/3.3
RAID chassis (fully populated with modules: maximum weight) 30/66
Expansion chassis (fully populated with modules: maximum weight) 25/55
Note 1: Weights shown are nominal, and subject to variances.
Note 2: 2U rail kits add between 2.8 kg (6.2 lb) and 3.4 kg (7.4 lb) to the aggregate chassis weight.
Note 3: Weights may vary due to different power supplies, controllers/expansion IOMs, and differ-
ing calibrations between scales.
Note 4: Weights may vary due to actual number and type of drives (SAS or SSD) and air manage-
ment modules installed.
