QXS-484 12G System Specifications 33
Chapter 4
QXS-484 12G System Specifications
This chapter provides the following information:
• QXS-484 12G: 5U84-Drive RAID and Expansion Chassis
• QXS-484 12G RAID and Expansion Physical Requirements
• QXS-484 12G RAID and Expansion Chassis Dimensions
• QXS-484 12G RAID and Expansion Rackmount Chassis Weights
QXS-484 12G: 5U84-Drive RAID and Expansion Chassis
This section provides 5U84-drive RAID and expansion chassis system component/CRU information.
Chassis is shipped without drives installed. Drives are shipped in two separate boxes (42 drives in each
box).
5U84-Drive Chassis
Figure 32 provides a front view of the 5U84-drive chassis.
Figure 32 5U84-Drive Chassis
