QXS-484 12G System Specifications 43
QXS-484 12G RAID and Expansion Chassis Dimensions
Tab l e 18 provides the 5U84 RAID and expansion chassis dimensions.
QXS-484 12G RAID and Expansion Rackmount Chassis
Weights
Tab l e 19 provides the chassis weights for the 5U84 RAID and expansion chassis.
Ta bl e 1 8 QXS 5U Chassis Dimensions
Specification Metric Unit Imperial Unit
Overall chassis height (5U) 222.3 mm 8.75 in
Width across mounting flange (located on front of chassis) 483 mm 19.01 in
Width across body of chassis 444.5 mm 17.50 in
Depth from face of mounting flange to back of chassis body 892.2 mm 35.12 in
Depth from face of mounting flange to rearmost chassis extremity 974.7 mm 38.31in
Depth from face of Ops panel to rearmost chassis extremity 981 mm 38.62 in
Note: The 5U84 uses 3.5" LFF disks in the DDIC carrier. It can also use 2.5" SFF disks with 3.5" adapter in the
DDIC.
Ta b le 1 9 5U84 RAID and Expansion Chassis Weights
CRU/Component 5U84 (kg/lb)
Storage chassis (empty) 64/141
Disk drive carrier 0.8/1.8
5U Power Supply Unit (PSU) 2.7/6.0
5U Fan 1.4/3.0
Controller (module in RAID chassis) 2.6/5.8
Expansion IOM (module in expansion chassis) 1.5/3.3
RAID chassis (fully populated with modules: maximum weight) 135/298
Expansion chassis (fully populated with modules: maximum weight) 13/287
Note 1: Weights shown are nominal, and subject to variances.
Note 2: 5U rail kits add significantly more weight.
Note 3: Weights may vary due to different power supplies, controllers/expansion IOMs, and
differing calibrations between scales.
Note 4: Weights may vary due to actual number and type of drives (SAS, SATA, or SSD)
installed.
