30 QXS 12G Site Planning Guide
Chassis Designators
The RAID and expansion chassis designators are as follows:
• 2U24 chassis (SFF):
• “2U24” denotes the 2.5” 24-drive chassis (with controller or expansion modules)
• The 2U24 chassis ships with drives installed.
• The chassis uses:
• 2.5” SAS
• 2.5” SATA
• Two controller modules or two expansion modules per chassis
• Two power supplies per chassis
QXS-324/424 12G RAID and Expansion Chassis Dimensions
Tab l e 13 provides the 2U24 RAID and expansion chassis dimensions.
QXS-324/424 12G RAID and Expansion Rackmount Chassis
Weights
Tab l e 14 provides the chassis weights for the 2U24 RAID and expansion chassis.
Ta bl e 1 3 2U24 RAID and Expansion Chassis Dimensions
Specification Metric Unit Imperial Unit
Overall chassis height (2U) 87.9 mm 3.46 in
Width across mounting flange (located on front of chassis) 483 mm 19.01 in
Width across body of chassis 443 mm 17.44 in
Depth from face of mounting flange to back of chassis body 576.8 mm 22.71 in
Depth from face of mounting flange to rearmost chassis extremity 602.9 mm 23.74 in
Depth from face of Ops panel to rearmost chassis extremity 629.6 mm 24.79 in
Note: The 2U24 chassis uses 2.5" SFF drives.
Ta b le 1 4 2U24 RAID and Expansion Chassis Weights
CRU/Component 2U24 (kg/lb)
Storage chassis (empty) 4.8/10.56
Disk drive carrier 0.3/0.66
Dummy disk drive carrier (air management sled) 0.05/0.11
2U Power Supply Unit (PSU) 3.5/7.7
Controller (module in RAID chassis) 2.6/5.8
