Radyne ComStream SFC6400A - Page 124

SFC6400A/SFC1450A Synthesized Frequency Upconverter Appendix B
TM106 – Rev. 1.1 B-7
<2>
<2>
<2>
<2>
<2>
<2>
<1>
<1>
<1>
<1>
<1>
<1>
<1>
<1>
<1>
<1>
<1>
<1>
Compensation
Prime 3
Compensation
Prime 4
Compensation
Prime 5
Compensation
Prime 6
Compensation
Prime 7
Compensation
Prime 8
Compensation
Compensation
Control
Backup Mode
Prime 1 Priority
Prime 2 Priority
Prime 3 Priority
Prime 4 Priority
Prime 5 Priority
Prime 6 Priority
Prime 7 Priority
Prime 8 Priority
Major Alarm
Mask
Minor Alarm
Mask
Binary value, one implied decimal point
Binary value, one implied decimal point
Binary value, one implied decimal point
Binary value, one implied decimal point
Binary value, one implied decimal point
Binary value, one implied decimal point
0 = Disable, 1 = Enable
0 = Manual, 1 = Automatic
0 - 8 (0 means not part of the backup pool)
0 - 8 (0 means not part of the backup pool)
0 - 8 (0 means not part of the backup pool)
0 - 8 (0 means not part of the backup pool)
0 - 8 (0 means not part of the backup pool)
0 - 8 (0 means not part of the backup pool)
0 - 8 (0 means not part of the backup pool)
0 - 8 (0 means not part of the backup pool)
Bit 0 = Polling Fault
Bit 1 = Relay Fault
Bits 2 - 7 = Spares
Bit 0 = Learned Fault
Bit 1 = Backup Test Fault
Bits 2 - 7 = Spares
