SFC6400A/SFC1450A Synthesized Frequency Upconverter Appendix B
TM106 – Rev. 1.1 B-9
Opcode: <3013h> Command set gain for the given channel
<4>
<1>
Gain
Channel
-20.0 dB to +30.0 dB depending on input attenuator setting
1 - 30
Opcode: <3014h> Command set channel
<1> Channel 1 - 30
Opcode: <3015h> Command set carrier control
<1> Carrier Control 0 = Off, 1 = On
Opcode: <3016h> Command set input attenuation
<1> Input Attenuation 0 - 31, Upconverter only
Opcode: <3017h> Command set converter configuration
<1> Converter Config 0 = Single
1 = 1F1 Primary
2 = 1F1 Backup
3 = 1F8 Primary
4 = 1F8 Backup
Opcode: <3018h> Command set converter alarm masks
<1>
<1>
Major Alarm
Mask
Minor Alarm
Bit 0 = LO Fault
Bit 1 = Signal Fault
Bits 2 - 7 = Spares
Bits 0 - 7 = Spares
B.5 Switch Commands
Opcode: <3030h> Command set backup mode
<1> Backup Mode 0 = Manual, 1 = Automatic
Opcode: <3031h> Command force a manual backup
<1> Prime To
Backup
1 - 8, converter must be present
Opcode: <3032h> Command learn converter configuration
<1> Prime To Learn 1 - 8, converter must be present
Opcode: <3033h> Command learn all converter configurations
(No data field for this opcode)
Opcode: <3034h> Command backup test converter configuration
