Appendix B SFC6400A/SFC1450A Synthesized Frequency Upconverter
B-6 TM106 – Rev. 1.1
<1>
<1>
<1>
<1>
<1>
Reference Type
Converter Config
Switch Config
Major Alarm
Mask
Minor Alarm
Mask
0 = Internal, 1 = External
0 = Single
1 = 1F1 Primary
2 = 1F1 Backup
3 = 1F8 Primary
4 = 1F8 Backup
TBD
Bit 0 = LO Fault
Bit 1 = Signal Fault
Bits 2 - 7 = Spares
Bits 0 - 7 = Spares
B.3 Switch Queries
Opcode: <3002h> Query switch status
Query response
<1>
<1>
<1>
<1>
<1>
Major Alarm
Status
Minor Alarm
Status
Latched Major
Alarm Status
Latched Minor
Alarm Status
Backed Up
Prime
Bit 0 = Polling Fault
Bit 1 = Relay Fault
Bits 2 - 7 = Spares
Bit 0 = Learned Fault
Bit 1 = Backup Test Fault
Bits 2 - 7 = Spares
Bit 0 = Polling Fault
Bit 1 = Relay Fault
Bits 2 - 7 = Spares
Bit 0 = Learned Fault
Bit 1 = Backup Test Fault
Bits 2 - 7 = Spares
0 - 8, backed Upconverter, 0 means no backup in progress
Opcode: <3003h> Query switch configuration
Query response
<2>
<2>
Prime 1
Compensation
Prime 2
Binary value, one implied decimal point
Binary value, one implied decimal point
