R&S FSH series User Manual

126
PD 1309.6269.62-02
P
Power and return loss (measuring) 90
power measurement 85
Power sensor (connection) 40
power supply unit 35
Preamplifi er 75
Preset 54
Putting into Operation 28
R
Reference frequency
adjust automatically 120
reference level 80
Regional settings 50
Return loss Measurement 100
Return loss measurement (calibration) 104
RF Attenuator 71
RF input 38
S
Safety Instructions 3
Saving and recalling settings and test results
115
Screen Settings 46
Self alignment 53
Setting date and time 51
Settings
date 51
date format 51
display backlight 46
display color scheme 47
key click volume 48
language 50
reference level 80
system beeper volume 49
time 52
GalaxyE_v1-10_3.indd 126GalaxyE_v1-10_3.indd 126 08.04.2009 15:21:5408.04.2009 15:21:54

R&S FSH series Specifications

General

Input Impedance	50 Ω
Display	640 x 480 pixels
Tracking generator	Optional
Interfaces	USB, LAN
Third Order Intercept (TOI)	+15 dBm typical
Input VSWR	≤1.5:1 (typical)
Input Connector	N (f)
Power Supply	100 V to 240 V
Frequency range	9 kHz to 3.6/8/13.6/20 GHz
Battery life	Approx. 4 hours (standard battery)
