R&S FSH series User Manual

39
E-02
Tracking generator output
(general output, models 1309.6000.14, 1309.6000.18,
1309.6000.24 and 1309.6000.28 only)
The tracking generator output power for the
different R&S FSH models is as follows:
Model: R&S FSH4 (1309.6000.14, 1309.6000.18)
Frequency: 100 kHz to 3.6 GHz
Tracking generator output power: 0 dBm nominal
Model: R&S FSH8 (1309.6000.24, 1309.6000.28)
Frequency: 300 kHz to 3.6 GHz
Tracking generator output power: 0 dBm nominal
Model: R&S FSH8 (1309.6000.24, 1309.6000.28)
Frequency: 3.6 GHz to 8 GHz
Tracking generator output power: -5 dBm nominal
The tracking generator output power can be
reduced with an integrated step attenuator by a
maximum of 40 dB in 1 dB steps in all R&S FSH
models.
Risk of damage to the tracking generator output
The reverse voltage up to the voltage stated on the
R&S FSH housing must not be exceeded.
GalaxyE_v1-10_3.indd 39GalaxyE_v1-10_3.indd 39 08.04.2009 15:21:4208.04.2009 15:21:42

R&S FSH series Specifications

General

Input Impedance	50 Ω
Display	640 x 480 pixels
Tracking generator	Optional
Interfaces	USB, LAN
Third Order Intercept (TOI)	+15 dBm typical
Input VSWR	≤1.5:1 (typical)
Input Connector	N (f)
Power Supply	100 V to 240 V
Frequency range	9 kHz to 3.6/8/13.6/20 GHz
Battery life	Approx. 4 hours (standard battery)
