R&S FSH series User Manual

87
E-02
The R&S FSH changes to power measurement
mode and opens the screen for the power
measurement. If a power sensor has not been
connected, no measured value is displayed. If a
power sensor has been connected, the R&S FSH
sets up a connection via the interface and, after a
few seconds, displays the measured power.
If there are any communication problems with
the power sensor, the R&S FSH outputs error
messages (sensor error: error number) indicating
the possible causes (see main manual).
To compensate for internal offset of the power
meter, it needs to be compensated before starting
the measurement.
 Press the ZERO softkey.
The R&S FSH outputs a message telling you not to
apply any signals to the power meter while zeroing
is being performed.
 Disconnect the power sensor from any signal
sources.
 Start zeroing with the softkey CONTINUE.
GalaxyE_v1-10_3.indd 87GalaxyE_v1-10_3.indd 87 08.04.2009 15:21:4908.04.2009 15:21:49

R&S FSH series Specifications

General

Input Impedance	50 Ω
Display	640 x 480 pixels
Tracking generator	Optional
Interfaces	USB, LAN
Third Order Intercept (TOI)	+15 dBm typical
Input VSWR	≤1.5:1 (typical)
Input Connector	N (f)
Power Supply	100 V to 240 V
Frequency range	9 kHz to 3.6/8/13.6/20 GHz
Battery life	Approx. 4 hours (standard battery)
