Chapter 2: MasterConsole Digital KVM Switches
7
 Support the video resolution up to 1920x1200@75Hz (analog) or
1920x1080@60Hz (digital)
 Multi-platform support, including MS-DOS, Windows® 7/8/8.1/10,
Linux® (Red Hat, Novell® Suse), Macintosh® OS9, OSX and SCO
UNIX®
 With the “keep-alive” technology, you can add, remove, and
hot-swap components without interruption to servers
 Simple operation with hot keys and On-Screen Display (OSD) menu
 Support the
Scan function, which can cycle through either all
channels or "active" channels only, and therefore update the channel
status
Note: For the definition of an "active" channel, see Active and
Inactive Channels (on page 45).
 Password protection prevents unauthorized access to MCD devices
and servers -- one administrator and 127 user accounts
 Easy firmware upgrade
MCD Package Contents
 MCD KVM switch x 1
 Power cord x 1
 Rackmount kit x 1 (including brackets and associated screws)
 DVI-I to VGA adapter x 1
Note: This adapter can be used for connecting a VGA monitor or for
connecting a 2nd-tier MCD switch via "MDUTP". For details, see Step
B: Connect the Keyboard/Mouse/Monitor
(on page 21) or
Establishing a Two-Tier System (on page 49).
 Warranty card x 1
 Quick Setup Guide x 1
MCD Structure Diagrams
This section provides a brief introduction to the components on the front
and rear sides of the MCD switch. The following diagrams illustrate
MCD-232.
