In This Chapter
One-User MCD Models..............................................................................73
Dual-User MCD Models.............................................................................74
One-User MCD-LED Models ..................................................................... 76
One-User MCD Models
Items MCD-108 MCD-116
Supported console users
1 1
Channel ports (female RJ-45)
8 16
Female USB-A ports (for keyboard/mouse)
2 2
Female DVI-I ports (for video output)
1 1
Female 3.5mm audio jack (for audio output)
1 1
Female Micro USB (for firmware upgrade)
1 1
Reset button (for power cycle)
1 1
AC socket
1 1
Power switch
1 1
Channel LEDs (white, but turn green when
accessed)
8 16
Power LED (blue)
1 1
Maximum number of servers with a two-tier
system comprising the same models
128 256
Appendix A Specifications
