Batterydata
The[Battery]datacategoryincludesitemsrelatedtoyourbatterystatus.
Thenumberofbatteriesthataredetectedbyyourperformancedisplayis
determinedbythenumberofbatteriesspecifiedunderyourmultifunction
display/chartplotter’
s[Boatdetails]settingsmenu:[Homescreen>Settings
>Boatdetails>Numofengines].Formoreinformationonhowtoconfigure
yourmultifunctiondisplay/chartplotter’s[Boatdetails]settingsmenu,refer
totheLightHouse™4AdvancedOperationInstructions(81406).
Thefollowingdataitemsareavailableinthe[Battery]datacategory:
DataitemsWidgettypesavailable
•[Batteryvoltage]
•[Batterycurrent]
•[S
tateofcharge]
•[Batterytemperature]
•[Digits]
•[90°gauge(left/right)]
•[180°gauge(up/down/left/
right)]
•[270°gauge]
•[Level]
[Timetillzerocharge][Digits]
Boatdata
Inorderforboatdatatobedisplayedonyourperformancedisplay ,a
compatiblesensormustbeconnectedtoyourmultifunctiondisplay/
chartplotternetwork.
Thefollowingdataitemsareavailableinthe[Boat]datacategory:
DataitemsWidgettypesavailable
[Rudderangle]•[Digits]
•[180°gauge(up/down)]
•[Rudderbar]
•[R ateofturn]
•[Roll]
•[Digits]
•[180°gauge(up/down)]
DataitemsWidgettypesavailable
[Pitch]•[Digits]
•[180°gauge(left/right)]
•[Mastrotation]
(1)
•[T
rimtabs]
[Digits]
Note:
(1)Thisdataitemisonlyavailablewhentheboatingactivityissetto
[Sailing]duringyourconnectedmultifunctiondisplay/chartplotter’
sinitial
startupwizard.
Depthdata
Inorderfordepthdatatobedisplayedonyourperformancedisplay,a
compatiblesonartransducermustbeconnectedtoyourmultifunctiondisplay
/chartplotternetwork.
Thefollowingdataitemsareavailableinthe[Depth]datacategory:
DataitemsWidgettypesavailable
[Depth]•[Digits]
•[Graph(horizontal)]
•[Graph(vertical)]
•[Mindepth]
•[Maxdepth]
[Digits]
Distancedata
Inorderfordistancedatatobedisplayedonyourperformancedisplay,a
compatiblespeedtransducerand/orGNSSreceivermustbeconnectedto
yourmultifunctiondisplay/chartplotternetwork.
Thefollowingdataitemsareavailableinthe[Distance]datacategory:
