Raymarine ALPHA - Engine Data

DataitemsWidgettypesavailable
•[L
og]
•[Trip]
•[Groundlog]
•[Trip(day)]
•[Trip(month)]
•[Trip(season)]
•[Distancetotack]
(1)
•[Trip(manual)]
•[Distancetostartline]
(1)
•[Linebias]
(1)
•[Distancetoempty]
•[DMG(Distancemadegood)]
•[DTW(Distancetowaypoint)]
•[SailingDTW]
•[XTE(Crosstrackerror)]
[Digits]
Note:
(1)Thisdataitemisonlyavailablewhentheboatingactivityissetto
[Sailing]duringyourconnectedmultifunctiondisplay/chartplotter’ sinitial
startupwizard.
Enginedata
Inorderforenginedatatobedisplayedonyourperformancedisplay ,an
enginemanagementsystemmustbeconnectedtoyourmultifunction
display/chartplotternetwork.Dependingonyourenginemanufacturer,a
compatibleengineinterfaceorgatewaymayberequired.
Thenumberofenginesthataredetectedbyyourperformancedisplayis
determinedbythenumberofenginesspecifiedunderyourmultifunction
display/chartplotter’s[Boatdetails]settingsmenu:[Homescreen>Settings
>Boatdetails>Numofengines].Formoreinformationonhowtoconfigure
yourmultifunctiondisplay/chartplotter’s[Boatdetails]settingsmenu,refer
totheLightHouse™4AdvancedOperationInstructions(81406).
Thefollowingdataitemsareavailableinthe[Engine]datacategory:
DataitemsWidgettypesavailable
—
[Enginecombogauge]
[Alternator]•[Digits]
•[90°gauge(left/right)]
•[180°gauge(up/down/left/
right)]
•[270°gauge]
•[Graph(horizontal)]
•[Graph(vertical)]
•[Boostpressure]
•[Coolantpressure]
•[Coolanttemperature]
•[EngineRPM]
•[Oilpressure]
•[Oiltemperature]
•[T
ransmissionoilpressure]
•[Fuelflow]
•[Fuelflow(instantaneous)]
•[Fuelflow(average)]
•[Fuelpressure]
•[Transmissionoiltemperature]
•[Digits]
•[90°gauge(left/right)]
•[180°gauge(up/down/left/
right)]
•[270°gauge]
•[Level]
[Engineload]•[Digits]
•[180°gauge(up/down/left/
right)]
•[270°gauge]
Widgetcreationandcustomization
43
