Chapter 5: Standard Chart Operations 5-37
Transferring
Waypoints and
Routes
If the operation fails, the Save Failed message is displayed.
➤ To receive incoming waypoints on SeaTalk or NMEA:
1. To display the waypoint list, press MARKS followed by the WAYPOINT LIST
soft key.
2. Press the WAYPOINT TRANSFER soft key.
3. Press the soft key RECEIVE WPTS FROM ST/NMEA.
The soft key changes to STOP RECEIVING WAYPOINTS.
When waypoints are transmitted by other equipment they are added to the
waypoint list on the chartplotter. Routes transmitted on NMEA are
appended to the route list.
4. To disable waypoint transfer, press the soft key STOP RECEIVING WAY-
POINTS.
Alternatively, press ENTER, or CLEAR, twice to close the Waypoint List.
D5595-1
USER CARD PRESENT
SAVE COMPLETE
SAVED 2 ROUTE(S) AND
7 WAYPOINT(S)
USER CARD MENU
LOAD WPT/
RTE DATA
FROM CARD
SAVE WPT/
RTE DATA
TO CARD
CHECK
CARD IN
USER SLOT
LOAD WPT/
RTE DATA
FROM CARD
SAVE WPT/
RTE DATA
TO CARD
CHECK
CARD IN
USER SLOT
USER CARD NOT PRESENT
SAVE FAILED
NO OR INCORRECT CARD
ENSURE USER CARD IS CORRECTLY
INSERTED IN THE LOWER SLOT
USER CARD MENU
D5596-1
MARKS
WAYPOINT
LIST
WAYPOINT
TRANSFER
