Raymarine RAY73 - Troubleshooting

15.
1Troubleshooting
Thetroubleshootinginformationprovidespossiblecausesandcorrectiveactionrequiredforcommon
problemsassociatedwithinstallationandoperationofyourproduct.
Beforepackingandshipping,allRaymarineproductsaresubjectedtocomprehensivetestingand
qualityassuranceprograms.Ifyoudoexperienceproblemswithyourproductthissectionwillhelp
youtodiagnoseandcorrectproblemsinordertorestorenormaloperation.
Ifafterreferringtothissectionyouarestillhavingproblemswithyourproduct,pleaserefertothe
TechnicalsupportsectionofthismanualforusefullinksandRaymarineProductSupportcontact
details.
Performingasystemreset
Note:P erformingaresetwillnotresetMMSIandATISIDnumber.
FromtheMaintenancemenu: Menu>Set-up>Maintenance.
1.Select
Systemreset.
2.Select Yes.
Thesystemisnowresettofactorydefaults.
Note:P erformingtheresetwilldeleteallcontactsinyourphonebookandresetalluseroptions.
S ystemtest
Thesystemtestmenucanbeusedtoshowthestatusofthesystemandconnecteddevices.
TheSystemtestmenushowthestatusofthefollowingsystemcomponentsandconnecteddevices:
•GPS
•DSC
•Battery
•Hailer
•Remotehandset
•OKisdisplayednexttoeachitemthatiseitherconnectedorenabled
•Noisdisplayednexttoitemsthatareeithernotconnectedordisabled.
CheckingforRFinterference
Ifyoususpectadevicemaybecausingradiofrequency(RF)interferenceyoucanuseyourVHF
radiotocheck.
1.Turnoffthesuspectdevice.
2.TuneyourVHFradiotoaquietchannelsuchasChannel13.
3.Adjustyourradio’sSquelchcontroluntiltheradiooutputsaudionoise.
4.Re-adjustyourradio’sSquelchcontroluntiltheaudioisquiet,onlyslightlyabovethenoise
threshold.
5.Turnonthesuspectdevice.
•Iftheradio’saudionoiseincreasesthenthedeviceiscausingRFinterference.
•Ifthereisnochangeintheradio’saudionoisethenthedeviceisnotcausingRFinterference.
Note:IfRFinterferenceispresentthenitislik elythatbothVHFandAISreceptionarebeing
degradedbythedevice.
Multipleantennainstallations
Importantadditionalconsiderationswheninstallingmultipleantennas.
T
opreventpotentialchannelinterferencewheninstallingtwoormoreVHFradiosonthesame
vessel,ensurethattheantennasarelocatedatleast2.4m(8ft.)awayfromeachother.
152
