Raymarine RAY73 - Product Dimensions - Wireless Handset and Holster

To Next Page

To Previous Page

7Productdimensions-Wirelesshandsetandholster

173.33mm(6.82in)

50 .5mm(1.99in)

71.41mm(2.81in)

Thechargingholsterissuppliedwithaﬁtted2meter(6.56ft)powercableterminatedwithbare

endedwires.
