5.

1Productdimensions—Ray53

Panelmountdimensions

A

168mm(6.6in)

B

156mm(6. 1in)

C

88.5mm(3.5in)

D

134mm(5.3in)

E

39 .75mm(1.6in)

F

21.5mm0 .85in)

G

59mm(2.3in)

H

25mm1.0in)

I

143.6mm(5. 7in)

Brack etmountdimensions

A

192.5mm(7 .6in)

B

121mm(4.8in)

C

173. 75mm(6.8in)

D

25mm(1in)

38
