5.6Productdimensions-Wirelesshub

Thedimensionsforthewirelesshubareshownbelow

26. 7mm(1.05in)

68.04mm(2.68in)

32. 16mm(1.27in)

70mm(2. 76in)

109 .2mm(4.30in)

121.6mm(4. 79in)

6.2mm(0 .24in)

87 .72mm(3.45in)

29 .14mm(1.15in)Min

106.95mm(4.21in)Max

244.99mm(9 .65in)

TheWirelesshubincludesaﬁtted5m(16.4ft)cableforconnectiontoyourVHFR adio.

Iftheinstallationrequiresthecabletobepassedthroughabulkheadorpanellinga20mm(0.79in)

diameterholeisrequiredtoallowtheconnectortopassthrough.

Productdimensions43
