1LEDdiagnostics—Ray90/Ray91Basestation
SequenceColorS
tatus
Green•Sea
Talkng®Bushealthy,no
communicationfaults.
•Allmodulesready(GPS,VHF,
AIS).
R
ed
•SeaTalkng®Busnot
connected.
•NMEA0183notconnected.
Red
•Connectedbutnotreceiving
data.
Green
•VHFtransceivermodule
initializing/notready.
Green
•GNSS(GPS)sensor
initializing/notready
.
Red
•Internalfault(NoGNSS(GPS)
signal,Noantenna,lost
signal).
11.2LEDdiagnostics-Wireless(Active)speak er
SequenceColorS tatus
PurplePoweringon
RedandBlue
Readytopair/connect
RedPairedok
Red
Connected,noaudio
