Raymarine RAY91 - Product Dimensions; Product Dimensions - Base Station

3.4Productdimensions
Productdimensions-Basestation
TheBasestationdimensionsarelistedbelow
.
A
217mm(8.54in)
B
9 .5mm(0.37in)
C
235.95mm(9 .29in)
D
104mm(4.09in)
E
149 .95mm(5.91in)
F
30mm(1. 18in)
G
14mm(0 .55in)
H
90mm(3.54in)
I
61mm(2.40in)
TheBasestationincludesafittedpowercableanddatacable ,Thepowercablelengthis1.2m(3.94
ft)andtheDatacablelengthis420mm(1.38ft).
34
