Raymarine RAY91 - Handset Station Connection

Important:T
oensurepowercables(includinganyextension)areofasufficientgauge,ensure
thatthereisacontinuousminimumvoltageof10.8Vdcattheendofthecablewhereitenters
theproduct’spowerconnector,evenwithafullyflatbatteryat11Vdc.(Donotassumethataflat
batteryisat0Vdc.Duetothedischargeprofileandinternalchemistryofbatteries,thecurrent
dropsmuchfasterthanthevoltage.A“fullyflat”batterystillshowsapositivevoltage,evenifit
doesn’thaveenoughcurrenttopoweryourdevice.)
Grounding
Ensurethatyouobserveanyadditionalgroundingadviceprovidedintheproduct’
sdocumentation.
Moreinformation
Itisrecommendedthatbestpracticeisobservedinallvesselelectricalinstallations,asdetailed
inthefollowingstandards:
•BMEACodeofPracticeforElectricalandElectronicInstallationsinBoats
•NMEA0400InstallationStandard
•ABYCE-11AC&DCElectricalSystemsonBoats
•ABYCA-31BatterychargersandInverters
•ABYCTE-4LightningProtection
4.4Handsetstationconnection
AWiredhandsetcanbeconnectedtoeachHandsetstationconnection(HS1/HS2).Yourradiois
suppliedwiththeequipmenttocreateafullhandsetstation(i.e.:Wiredhandset,Adaptorcableand
Passivespeaker).Additionalaccessoriescanbepurchasedtocreateasecondwiredhandsetstation.
1.Basestation
2.P assivespeaker(1xsuppliedandavailableasaccessory:A80542)
3.Wiredhandset(1xsuppliedandavailableasaccessory:A80289)
4.HandsetstationadaptorcablewithRCAAudio400mm(1.3ft)(1xsuppliedandavailableas
accessory:A80297)
5.Wiredhandsetextensioncable(Availableoptionalaccessories:A80290–5m,A80291–10
mor15–A80292)
6.Panelmountfixingskit(1xsuppliedandavailableasaSpare:R70438)
Connectinghandsetsandcables
Followthestepsbelowtoconnecthandsetsandextensioncablestogether.
1.Iffitted,unscrewandremovethedustcapfromtherelevantconnector.
2.Ensurethecableconnectorsarecorrectlyorientated,beforeinsertion.
3.Ensureconnectorsarefullyinserted,beforelocking..
54
