In-linefuseandthermalbreak

erratings

Thewirelessspeakerisinternallyfused,howeveritisrecommendedthatyouﬁtaninlinefuseonthe

positivewireofyourproduct’spowercableorconnectusingathermalbreaker.

In-linefuseratingThermalbreak

errating

2A(refertonotebelow)

Note:

•Thesuitablefuseratingforthethermalbreak

erisdependentonthenumberofdevicesyouare

connecting.IfindoubtconsultanauthorizedRaymarine

dealer.

4. 12Wirelesshandsetconnections

TheWirelesshandsetconnectswirelesslytotheWirelesshub,andtheWirelessspeakerconnects

wirelesslytotheWirelesshandset.

Upto3WirelesshandsetscanbeconnectedtotheWirelesshub .Referto6.2Connectinga

wirelesshandsettothehub

fortheconnectionprocedure.

OneWirelessspeakercanbeconnectedtoeachWirelesshandset.Referto6.3Connectingthe

wirelessspeakertotheWirelesshandset

fortheconnectionprocedure.

Cablesandconnections61
