1
W
aterprooffuseholdercontainingasuitably-ratedinlinefusemustbefitted.
Forsuitablefuserating,referto:
In-linefuseandthermalbreakerratings .
2
Productpowercable
.
3
Drainwireconnectionpoint.
•Itisrecommendedthatthesuppliedpowercableisconnectedtoasuitablebreak
erorswitchon
thevessel'sdistributionpanelorfactory-fittedpowerdistributionpoint.
•Thedistributionpointshouldbefedfromthevessel’sprimarypowersourceby8AWG(8.36mm
2
)
cable.
•Ideally,allequipmentshouldbewiredtoindividualsuitably-ratedthermalbreakersorfuses,with
appropriatecircuitprotection.Wherethisisnotpossibleandmorethan1itemofequipmentshares
abreaker,useindividualin-linefusesforeachpowercircuittoprovidethenecessaryprotection.
1
P ositive(+)bar
2
Negative(-)bar
3Circuitbreak er
4
W aterprooffuseholdercontainingasuitably-ratedinlinefusemustbefitted.
Forsuitablefuserating,referto: In-linefuseandthermalbreakerratings .
Important:
Observetherecommendedfuse/break erratingsprovidedintheproduct’sdocumentation,
howeverbeawarethatthesuitablefuse/breakerratingisdependentonthenumberofdevices
beingconnected.
Implementation—directconnectiontobattery
•Whereconnectiontoapowerdistributionpanelisnotpossible,thepowercablesuppliedwith
yourproductmaybeconnecteddirectlytothevessel' sbattery,viaasuitablyratedfuseorbreaker.
•ThepowercablesuppliedwithyourproductmayNOTincludeaseparatedrainwire.Ifthisisthe
case,onlythepowercable’sredandblackwiresneedtobeconnected.
•IfthepowercableisNOTsuppliedwithafittedinlinefuse,youMUSTfitasuitablyratedfuseor
breakerbetweentheredwireandthebattery’spositiveterminal.
•Refertotheinlinefuseratingsprovidedintheproduct’sdocumentation.
•Ifyouneedtoextendthelengthofthepowercablesuppliedwithyourproduct,ensureyou
observethededicated
Powercableextensions adviceprovidedintheproduct’sdocumentation.
52
