12
Safety functions
The machine is equipped with the safety functions de-
scribed as follows.
Electromagnetic brake
The electromagnetic brake (A) is integrated in the front
wheel's traction system and keeps the machine braked
when it is turned o and when it is on but stopped.
The key (A1) locks/releases the brake.
(see chapters: “PUSHING/TOWING THE MACHINE” and
“ELECTROMAGNETIC BRAKE”.
Traction safety micro-switch
It is installed in the driver's seat in zone (B) and does not
allow any machine operation if the driver is not seated.
Emergency stop button
It is on the control and commands panel in position (C); it
is easily accessible by the operator.
It must be pressed rmly if urgently required in order to
stop all machine functions.
Turn it clockwise too release it and restore all machine
operations.
C
A
B
D
D
A1
A1
Anti-tipping tubes
These are two tubes (D) on the right and left front parts
of the frame that prevent the machine from tipping over.
