Cleaning the detergent solution supply nozzle to the disc brush
(KILO version with disc brush base)
1. Remove the brush (See procedure in the speci c paragraph).
2. By acting on the coupling hub (A) of the brush, unscrew the ring nut (B) and recover the nozzle (C) and the gasket
(D).
3. Clean the nozzle (C).
4. Place the nozzle (C) and the gasket (D) in their seat and then screw the ring nut (B).
5. Reassemble the brush (See procedure in the speci c paragraph).
!
ATTENTION!
Appropriately protect body parts (eyes, hair, hands, etc.) when cleaning with compressed air or water guns.
B
C
A
E
B E
C F
D
G
