43
Charging the batteries, for machines with on-board battery charger (upon request)
1. Take the machine to a suitable area to charge the batteries.
2. Open the batteries holder case (see procedure in the previous paragraph) but do not disconnect the batteries
connector (D).
3. Only for lead batteries (WET):
• Check the correct level of the electrolyte inside the batteries (E); restore it through the cap (F) if necessary.
• Leave all caps (F) open for subsequent charging.
• Clean (if necessary) the upper surface of the batteries.
4. Connect the connector (G) to the electrical mains, after having checked that the mains nominal volt-
age is the one foreseen for charging the machine (Refer to the machine's technical data plate).
The batteries start charging.
NOTE!
When the battery charger is connected to the mains, all machine functions are automatically excluded.
5. Charging is complete when “100 %” is shown on the zone (H) of the display and the notches of the zone (I) are
all full.
6. Disconnect the electrical connection (G) from the mains.
7. Only for lead batteries (WET) Check the correct level of the electrolyte inside the batteries and close all the caps (F).
8. Close the batteries holder case (see procedure in the previous paragraph).
9. Charging is complete.
E
F
G
D
H I
E
F
