13
TECHNICAL DATA
Description
S02
(Disc brush base)
Voltage 24V
Cleaning width 530 mm
Drying width 600 mm
Vacuum 1168 mm H2O
Detergent solution (or washing water) tank capacity 65 L
Disc brush rpm 175 rpm
Number of disc brushes 1
Disc brush pressure 23 Kg
Washing speed 4 Km/h
Maximum speed 5 Km/h
Maximum working angle 10%
Batteries (nr.) 2 - 118Ah
Built-in battery charger √ (Upon request)
Max. washing capacity 2120 m²/h
Autonomy (hours) based upon 118 Ah batteries 2. 30’
Detersaver √ (Upon request)
> Mixing ratio 1-5%
Machine body dimensions with squeegee and brush
(length x height x width)
1340 x 1130 x 600 mm
Basic weight of the empty machine in operation
(with 118Ah batteries, with tanks empty, without operator on board)
235 Kg
Gross weight of the ready machine
(with 118Ah batteries, with full solution tank, without operator on board)
300 Kg
Drive motor 400 W
Disc brush motor 400 W
Vacuum motor 400 W (3 stages)
Manufacturing legislation EC
Sound pressure level (A) in operating position 72.4 dB (A)
