Renesas R8C series User Manual

R8C/1A Group, R8C/1B Group 12. Interrupts
Rev.1.30 Dec 08, 2006 Page 84 of 315
REJ09B0252-0130
Figure 12.4 INT0IC Register
INT0 Interrupt Control Register
(2)
Symbol Address After Reset
INT0IC
005Dh XX00X000b
Bit Symbol Bit Name Function RW
NOTES :
1.
2.
3.
4.
—
(b7-b6)
—
Nothing is assigned. If necessary, set to 0.
When read, the content is undefined.
Only 0 can be w ritten to the IR bit. (Do not w rite 1.)
—
(b5)
Reserved bit Set to 0.
RW
POL
Polarity sw itch bit
(4)
0 : Selects falling edge.
1 : Selects rising edge.
(3)
RW
IR
Interrupt request bit 0 : Requests no interrupt.
1 : Requests interrupt.
RW
(1)
ILV L0 RW
Interrupt priority level select bits
b2 b1 b0
0 0 0 : Level 0 (interrupt disable)
0 0 1 : Level 1
0 1 0 : Level 2
0 1 1 : Level 3
1 0 0 : Level 4
1 0 1 : Level 5
1 1 0 : Level 6
1 1 1 : Level 7
ILV L1 RW
ILV L2 RW
b0
0
Rew rite the interrupt control register w hen the interrupt request w hich is applicable for the register is not generated.
Refer to
12.5.6 Changing Interrupt Control Registers.
If the INTOPL bit in the INTEN register is set to 1 (both edges), set the POL bit to 0 (selects falling edge).
The IR bit may be set to 1 (requests interrupt) w hen the POL bit is rew ritten. Refer to
12.5.5 Changing Interrupt
Sources.
b7 b6 b5 b4 b3 b2 b1
