R8C/1A Group, R8C/1B Group 19. Electrical Characteristics

Rev.1.30 Dec 08, 2006 Page 286 of 315

REJ09B0252-0130

Figure 19.6 I/O Timing of Clock Synchronous Serial I/O with Chip Select (Clock Synchronous

Communication Mode)

VIH or VOH

tHI

tLO tSUCYC

tOD

tSU

SSCK

SSO (output)

SSI (input)

VIH or VOH
