C - 2
REVISION HISTORY R8C/1A Group, R8C/1B Group Hardware Manual
1.00 Sep 09, 2005 33 Table 5.18 Unassigned Pin Handling, Figure 5.11 Unassigned Pin
Handling;
“Port P4_2, P4_6, P4_7
“Port P4_6, P4_7
“VREF”
“Port P4_2/VREF” revised
53 Table 9.2 Bus Cycles for Access Space of the R8C/1B Group added,
Table 9.3 Access Unit and Bus Operation;
“SFR”
“SFR, Data flash”,
“ROM/RAM”
“Program ROM, ROM, RAM” revised
62 10.2.1 Low-speed On-Chip Oscillator Clock;
“The application products ... to accommodate the frequency range.”
“The application products ... for the frequency change.” revised
10.2.2 High-Speed On-Chip Oscillator Clock;
“The high-speed on-chip oscillator frequency ... for details.” added
69 10.5.1 How to Use Oscillation Stop Detection Function;
“This function cannot ... is 2 MHz or below.”
“This function cannot be ... is below 2 MHz.” revised
70 Figure 10.9 Procedure of Switching Clock Source From Low-Speed On-
Chip Oscillator to Main Clock revised
71 10.6.2 Oscillation Stop Detection Function;
“Since the oscillation ...frequency is 2MHz or below, ...”
“Since the oscillation ...frequency is below 2MHz, ...” revised
10.6.4 High-Speed On-Ship Oscillator Clock added.
85 Figure 12.10 Judgement Circuit of Interrupts Priority Level;
NOTE2 deleted
104 Figure 14.1 Block Diagram of Timer X;
“Peripheral data bus”
“Data Bus” revised
117 14.1.6 Precautions on Timer X;
“When writing “1” (count starts) to ... writing “1” to the TXS bit.”
‘ “0” (count stops) can be read ... after the TXS bit is set to “1”.’ revised
118 Figure 14.11 Block Diagram of Timer Z;
“Peripheral Data Bus”
“Data Bus” revised
135 14.2.5 Precautions on Timer Z;
“When writing “1” (count starts) to ... writing “1” to the TZS bit.”
‘ “0” (count stops) can be read ... after the TZS bit is set to “1”.’ revised
149 Figure 15.3 U0TB to U1TB, U0RB to U1RB and U0BRG to U1BRG
Registers;
“UARTi Transmit Buffer Register (i=0 to 1)” and
“UARTi Receive Buffer
Register (i=0 to 1)” revised
159 Table 15.5 Registers to Be Used and Settings in UART Mode;
UiBRG: “
“0 to 7” revised
164 Table 16.1 Mode Selection;
“RE and TE Bits in SSER Register” added
193 16.2.8.2 Selecting SSI Signal Pin added
