Revolectrix Dual PowerLab 8x2 User Manual

78
Bananas Removed
The bananas were removed when charging
Negative Amps
Check the supply wiring
Chg. Not Allowed
The preset will not allow charging
Cell V. Too Hi/L
The cell voltage is out of range
Pack Below 3.0V
The pack voltage is too low. Check the preset Flag Bad Pack setting
REPLACE BAD PACK
Check the preset Flag Bad Pack setting
Exp. Ch Com. Err
Check that all the chargers have a good common ground
Safety Code #78
High voltage when off
Safety Code #79
CH1CELLS out of range
Safety Code #80
Regenerative voltage setting is corrupt
Safety Code #81
CHSNUMBER stuck in loop
Safety Code #82
Amps out of range
Safety Code #83
Supply low volt setting is corrupt
Safety Code #84
Regen and charge enabled
Safety Code #85
Amps negative in charge
Safety Code #86
Amps positive in discharge
Safety Code #87
Regen with no discharge
Safety Code #88
AMPSDSCHRANGE in charge mode
Safety Code #89
Supply battery has changed
Safety Code #90
Unknown screen number
Safety Code #92
Mux number error
Safety Code #93
Calibration checksum bad. Send charger to factory
Safety Code #94
Bad EEPROM write
Safety Code #95
Bypass Over-volt Check node wiring or selected node wiring
Safety Code #96
PWM ratio too high. Check the power supply and output wiring
Safety Code #97
Amps were not read on startup
Safety Code #98
P_RAMPRESET not master
Safety Code #99
Bad mode number
Safety Code #100
Temperature out of range
Safety Code #105
Preset not factory validated
Safety Code #106
Preset number out of range
Safety Code #107
Charge timeout out of range
Safety Code #108
Preset loaded while charging
Safety Code #109
Charge termination unknown
Safety Code #110
Expansion channel found in mode 30
Safety Code #111
Preset cell over volts too high
Safety Code #112
MEASUREDDUTY16 > 1024
Safety Code #113
Charge PWM not regulating
Safety Code #114
Bad preset flash check while running
Safety Code #115
Bad preset flash checksum on start
Safety Code #116
Bad preset ram checksum on start
Safety Code #117
Bad segment checksum on start
Safety Code #118
Bad segment checksum while running
