4 Intended use
Danger of destruction of the device if not ex-
pressly stated accessories, mounting parts and
other components, cables, lines, software and
firmware are used.
NOTICE
The control may only be used with the accessories and mounting parts listed in
this documentation. Components that are not expressly mentioned must neither
be attached nor connected. The same is valid for cables and lines.
Operation must only be carried out with the hardware component configura-
tions and combinations that are expressly specified and with the software and
firmware indicated and specified in the respective documentation and functional
descriptions.
Typical fields of use of the controls are:
Handling systems and assembly systems
Packaging and food processing machines
Printing machines and paper converting machines
Machine tools
Woodworking machines
The controls may only be operated under the mounting and installation condi-
tions, the position, and the ambient conditions (temperature, degree of protec-
tion, humidity, EMC etc.) specified in this documentation.
5
Spare parts, accessories and wear parts
5.1 Connector set for the control
Ordering code Part number Description
R-IB IL CML S01 PLSET R911299856 2 input connectors, 2 output connectors and 1
power connector
R-IB IL CML S04 PLSET R911172193 2 input connectors, 2 output connectors and 1
power connector, continuously numbered
Tab. 5-1: Connector set for the controls L45, L65, L75 and L85
5.2 Connector set for the control L25
Ordering code Part number Description
R-IB IL SCN-PWR IN PWR R911171765 -
Tab. 5-2: Power connector for the control L25
Bosch Rexroth AG
Spare parts, accessories and wear parts
L25, L45, L65, L75 and L85
6/53
DOK-CONTRL-IC*LX5*****-IT02-EN-P
