9 Interfaces
9.1 Interface view
① to ⑩ Refer to tab. 9-1 "Control interfaces"
on page 15
⑦ Slot for Compact Flash card
⑪ PWR IN voltage supply
Fig. 9-1: Control interfaces
Destruction of the components due to the
mounting of the control, module, Inline termi-
nals or connectors under voltage!
● Before mounting or demounting components, disconnect the control - includ-
ing its components - from the voltage
● Connect the voltage only after the control and its components have been set
up
Bosch Rexroth AG
Interfaces
L25, L45, L65, L75 and L85
14/53
DOK-CONTRL-IC*LX5*****-IT02-EN-P
