2. Do not yet snap on the adjacent connector of the neighboring terminal to
the left.
3. Fit the new terminal.
4. Subsequently, attach all connectors again.
10.7 Electric installation
10.7.1 General information
Risk of injury due to incorrect mounting or elec-
tric installation!
● Any dangerous system states, which might cause personal injury, must be pre-
vented!
● Protection upon direct and indirect contact must be ensured by the specified
measures (connection to protective conductor, insulation, etc.).
10.7.2 External power supply unit
All control components are supplied from 24 V voltage supplies.
Use the Bosch Rexroth power supply unit VAP01.1H-W23-024-010-NN, part num-
ber R911171065, for the logic supply. For further information on the external
power supply unit and on the creation of overvoltage categories, refer to the
documentation of the power supply unit.
All lines of the 24 V voltage supply have to be wired separately from lines carry-
ing higher voltages.
All peripherals, such as digital sensors or actuators connected to the interfaces
of the control, also have to comply with the criteria of safety-separated circuits.
10.7.3 Voltage supply for the control
General information
The control as well as any connected function modules and Inline terminals are
supplied with power via the black power connector on the right side of the con-
trol.
Connect the power connector with cables with a conductor cross-
section of AWG 16-22 (0.34 mm
2
- 1.5 mm
2
).
Observe the color-coding of the plugs.
Bosch Rexroth AG
Mounting, demounting and electric installation
L25, L45, L65, L75 and L85
30/53
DOK-CONTRL-IC*LX5*****-IT02-EN-P
