If the 2-pin connection is incorrect, there is no
protection from GND breakage anymore.
The 0 V reference of the connected loads has to be returned to the 0 V connec-
tion of the control. I.e. a two-pin connection has to be ensured. Otherwise, pro-
tection from GND breakage is not ensured.
10.7.11 Further interfaces
Further interfaces (Ethernet, Profibus DP, Sercos, Ready contact, Compact Flash
card, Inline bus and function modules) are described in the project planning
manuals of the controls Rexroth IndraControl L45/L65/L75/L85 and Rexroth
IndraControl L25, see also "Related documents" on page 2.
Connect the Ready contact (X2R) using cables with a conductor
cross-section of AWG 16-24.
11 Commissioning
11.1 General information
Uncontrolled machine movement caused by op-
eration without Compact Flash card or by re-
moval of the Compact Flash card during opera-
tion.
Do not remove the Compact Flash card when the control is running!
11.2
Commissioning steps
To commission the control, further parameterization or programming is necessa-
ry.
To commission the device, proceed as follows:
1. Mount the control.
(For details, refer to chapter 10 "Mounting, demounting and electric instal-
lation" on page 16).
2. Insert the Compact Flash card with approved firmware.
3. Connect the power supply via the connectors from the connector set.
For details, please refer to chapter 10.7.3 "Voltage supply for the control"
on page 30 and the relevant project planning manuals.
4. Switch on the control
L25, L45, L65, L75 and L85
Bosch Rexroth AG
Commissioning
DOK-CONTRL-IC*LX5*****-IT02-EN-P
41/53
