For further information on the connection, please refer to the project planning
manual of the relevant control.
Possible malfunction if the contacts 2.1 and 2.2
are interchanged
NOTICE
For the controls L45, L65. L75 and L85 with a device index smaller than 201
(see also chapter 2.1 "Product identification" on page 3), the contacts 2.1 and
2.2 are interchanged.
For further information on the connection, refer to the respective project plan-
ning manual of the controls.
10.7.4 24 V voltage supply
General information
The voltage of 24 V can be supplied with or without electrical isolation.
Setup without electrical isolation
An easy connection method is the setup without an electrical isolation between
the internal logic and the peripheral supply.
In this case, a power supply unit is sufficient to supply the control.
The power output must not exceed 240 W!
The GND (U
LS
) is grounded in the device!
Bosch Rexroth AG
Mounting, demounting and electric installation
L25, L45, L65, L75 and L85
32/53
DOK-CONTRL-IC*LX5*****-IT02-EN-P
