Potential equalization
Potential equalization acc. to DIN VDE 0100 part 540 has to be provided be-
tween the system parts and the voltage supply.
Information on the protective conductor system
All system components have to be connected to the PE protective conductor sys-
tem at the connectors marked accordingly.
10.7.6 Shielding
Production failure possible due to control fail-
ure resulting from insufficient shielding.
Provide sufficient shielding.
The shielding reduces any effects of interferences on the system.
Observe the following when shielding:
● Fasten the shielding as extensively as possible
● Ensure proper contact between connector and terminal
Lay all power cables and data cables in separate cable channels.
10.7.7 Connecting lines (for digital onboard inputs, outputs and voltage
supply) to tension spring connection points
General information
Connect the lines for digital onboard inputs, onboard outputs and the voltage
supply to the control at the tension spring connection points.
Lines with an average conductor cross-section of 0.2 mm
2
to 1.5 mm
2
(AWG 16
to 24) can be connected.
Unshielded lines:
Use unshielded lines for the digital inputs and outputs as well as for the voltage
supply.
Bosch Rexroth AG
Mounting, demounting and electric installation
L25, L45, L65, L75 and L85
36/53
DOK-CONTRL-IC*LX5*****-IT02-EN-P
