1
1
2
① End clamps
② Top-hat rail
Fig. 10-12: End clamps
The end clamps are used as lateral termination elements.
10.4 Mounting the fan (if necessary)
X7E5
X2R
X7P
X7E3
X7E4
X7E1
X7E2
1
2
① Bottom side of the control
② Fan
Fig. 10-13: Mounting the fan
1. Put the fan
② onto the control ①, see figure 10-13.
L25, L45, L65, L75 and L85
Bosch Rexroth AG
Mounting, demounting and electric installation
DOK-CONTRL-IC*LX5*****-IT02-EN-P
25/53
