9.2 Overview
Name at housing
(no. in graphic)
Connection type Connector type
(Integrated)
Mating connec-
tor and cable
(From outside)
Note on device variants
X7E4
(①)
Ethernet
(TCP/IP, RT Ethernet)
RJ45 socket
8-pin
RJ45 plug
(Twisted pair,
4-/8-wire)
Availability:
● L25: Only on the device variant CML...PN...
● L45, L65, L75, L85: On all device variants
X7E3
(②)
Ethernet
(TCP/IP, RT Ethernet)
RJ45 socket
8-pin
RJ45 plug
(Twisted pair,
4-/8-wire)
Availability:
● L25: Only on the device variant CML...PN...
● L45, L65, L75, L85: On all device variants
X7E2
(③)
Ethernet
(Sercos)
RJ45 socket
8-pin
RJ45 plug
(Twisted pair,
8-wire)
Availability:
● L25: Only on the device variant CML...3N...
● L45, L65, L75, L85: On all device variants
X7E1
(④)
Ethernet
(Sercos)
RJ45 socket
8-pin
RJ45 plug
(Twisted pair,
8-wire)
Availability:
● L25: Only on the device variant CML...3N...
● L45, L65, L75, L85: On all device variants
X7E5
(⑤)
Ethernet
(TCP/IP, programming
device)
RJ45 socket
8-pin
RJ45 plug
(Twisted pair,
8-wire)
-
X2R
(⑥)
Ready contact Connector strip
3-pin, 3.5 mm
3-pin female
connector
strip, spring
force, 3.5 mm
(upon delivery)
-
(⑦) Slot for Compact
Flash card
Not specified Not Specified -
X7P
(⑧)
RS485
(Profibus DP)
D-SUB socket
9-pin
D-Sub bus con-
nector, IP 20,
9-pin
Availability:
● L25: Only on the device variant CML...PN...
● L45, L65, L75, L85: On all device variants
(⑨) 8 digital inputs Inline plug
8-pin
Inline socket
8-pin
Availability:
● L25: Not available
● L45, L65, L75, L85: On all device variants
(⑩) 8 digital outputs Inline plug
8-pin
Inline socket
8-pin
Availability:
● L25: Not available
● L45, L65, L75, L85: On all device variants
(⑪) PWR IN voltage supply Inline plug
8-pin
Inline socket
8-pin
-
Tab. 9-1: Control interfaces
L25, L45, L65, L75 and L85
Bosch Rexroth AG
Interfaces
DOK-CONTRL-IC*LX5*****-IT02-EN-P
15/53
